FM Radio sidemount dipole, 304 stainless steel, 87.5-108MHz, 500W, 0dBd – 1.4m

Broadband FM Radio sidemount dipole, 304 stainless steel, 87.5-108 MHz, 500W, N-type female, 1.5m cable, 0 dBd - 1.4m

Product code: B46BSS

The B46BSS sidemount dipole is an ideal choice for use as an FM radio broadcast antenna or as a standby boradcast antenna. It will cover a broad bandwidth and permit single antenna sharing with multiple FM transmit frequencies. ZCG recommend mounting the B46BSS as high on your tower or structure as possible using 1 x Y2300-SS mounting hardware.

download brochure
Download Radiation Pattern

Specifications

Frequency

87.5-108 MHz - FM Radio

Bandwidth

Full frequency range stated - 20.5 MHz

Gain

0 dBd - stacking increases gain

Tuning

Factory at better than 1.3:1 VSWR

Impedance

50 Ohms

E Plane beamwidth

110°

Maximum Power

500 Watts

Polarisation

Vertical

Construction

304 grade stainless steel dipole, stand-off mount section, 1.5m external RG213 cable and N-female connector

Connector

N-type female fitted to 1.5 metre RG213 coaxial cable

Dimensions

Dipole height: 1.4m, Dipole stand-off: 1.5m x 38.1mm O.D.

Weight - kg

7

Wind load at 160kph

10.875kg, 0.107kN
