Ground independent UHF stainless steel whip, 420-520 MHz, specify 15MHz, 2.1 dBi – 1.1m

Ground independent UHF stainless steel whip, 420-520 MHz, specify 15 MHz, UHF male PL259, 4.5m cable, 2.1 dBi - 1.1m

Product code: GRUFC

The GRUFC ground independent UHF half-wave, end-fed whip is a lightweight UHF communications antenna, suitable for low weight bearing locations on your vehicle or structure. The GRUFC comes standard with 4.5 metres RG58 Low Loss fitted with a FME Female for ease of installation and a FME Female to UHF Male PL259 adaptor supplied which is compatible with any UHF Radio or UHF Device on the market. Mounting of the GRUFC is using a minimum 13mm hole or appropriate bracket.

download brochure
Download Installation Guide

Specifications

Frequency

420-520 MHz - UHF, TETRA and LMR compatible

Bandwidth

Specify 15 MHz bandwidth when ordering, can be field tuned if required

Gain

2.1 dBi - suits hilly terrain, CBD locations or low gain requirements

Tuning

Factory at better than 1.5:1 VSWR

Impedance

50 Ohms

H Plane beamwidth

360° omnidirectional ± 0.5 dBd

Maximum Power

50 Watts

Polarisation

Vertical

Construction

Type 17-7PH stainless steel whip, machined black delrin base ferrule, internal coil loaded base, fixed 4.7m external RG58 cable, FME connector and FME-UHF adaptor

Connector

FME female fitted to cable for ease of installation. FME male to UHF male PL259 adaptor supplied for coax to device connection

Dimensions

Height: 1.1m, Mount hole requirements: min. 10mm

Weight - kg

0.360
