Microwave link STL grid-pack, aluminium, 1400-1550 MHz, 100W, N-type female, 7.6° beamwidth, 26.3 dBi – 1.8m

Microwave link STL grid-pack, aluminium, 1400-1550 MHz, 100W, N-type female, 7.6° beamwidth, 26.3 dBi - 1.8m

Product code: MGP-1500N

The MGP-1500N high gain UHF STL link antenna is an ideal solution for a long distance, highly directional STL link utilising 1400-1550 MHz range. The MGP-1500N STL grid-pack antenna is a two-piece rear dish design for easier storage and reduced delivery cost, please note assembly of the rear screen and launcher unit is required. The MGP-1500N high gain STL link antenna covers the ACMA allocated PTP 1431.5-1534MHz frequency range.

download brochure
Download Installation Guide
Download Radiation Pattern

Specifications

Frequency

1.4-1.55 GHz - incl. ACMA allocated PTP 1431.5-1534 MHz

Bandwidth

Full frequency range stated - 150 MHz

Gain

26.3 dBi - nominal

Tuning

Factory at better than 1.5:1 VSWR

Impedance

50 Ohms - nominal

H Plane beamwidth

10°

E Plane beamwidth

7.6°

Maximum Power

100 Watts

Polarisation

Mount horizontal or vertical as required, utilising tilt adjustable mount brackets. Strut support supplied.

Isolation

Cross pol. Discrimination: >-28dB

Front-to-back

>30dB

DC grounded

Yes

Construction

2-piece welded corrosion resistant aluminium rear parabolic screen, detachable launcher unit, tilt/pan adjustable mount brackets and support strut

Connector

N-type female jack in rear of launcher unit, no cable

Dimensions

Diameter: 1.8m (6') x 1.85m

Weight - kg

30.0

Wind load at 160kph

194.7kg, 1.9kN
