Low P.I.M. N-type male clamp connector plug for 1/2″ super flexible cable – ZCG1250SF- tri-metal plated

N-type male clamp-style connector for 1/2" super flexible, helical coaxial cable, ZCG1250SF, DC-2.4 GHz, 50 Ohms - tri-metal plated

Product code: NM1250SF

The NM1250SF is a N-type male clamp-style coaxial connector for 1/2" super flexible, solid helical shielded, foam dielectric, solid core coaxial cable. The NM1250SF is rated for maximum 500 mating cycles.

download brochure
Download Installation Guide

Specifications

Frequency

DC to maximum 2.4 GHz

Impedance

50 Ohms - nominal

Maximum Power

500 Watts, 1kW - peak

Polarisation

Straight - clamp-style

Construction

Tri-metal plated body & securing nut, silver plated centre pin, PTFE insulator & neoprene O-rings

Connector

N-type male / N-male

Dimensions

Length: 48mm, Diameter: 19mm

Weight - kg

0.048
