Naval SPEC VHF Monocone, 316 stainless steel – 135-175MHz, weather sealed N-female, 500W, 0dBd – 1.3m

Naval SPEC VHF Monocone, 316 stainless steel – 135-175MHz, weather sealed N-female, 500W, 0dBd – 1.3m

Ruggedised broadband VHF monocone, 316 stainless steel, 135-175 MHz, weather sealed N-type female, 500W, 0 dBd - 1.3m

Product code: M56SS-MIL-VHF40

Designed and manufactured for the most extreme conditions the M56SS-MIL-VHF40 ruggedised VHF high band monocone antenna is suited for mounting into locations where our standard B56SS VHF high band mononcone's design isn't suitable, such as naval vessels or locations where extreme adverse weather is experienced such as remote locations. The N-type female is weather sealed inside a protective PVC cover with an external cable gland to seal the cable. ZCG recommend mounting the M56SS-MIL-VHF40 as high on your structure or vessel as possible using 2 or 3 x EB1-SS parallel mount clamps, 1 x UB3-SS parallel plate mount clamp or 2 or 3 x NSM-218 toughened nylon wall/side mount brackets.

download brochure

Download Installation Guide

Download Radiation Pattern

Specifications

Frequency

135-175 MHz - High band VHF

Bandwidth

Full frequency range stated - 40 MHz

Gain

0 dBd - unity

Tuning

Factory at <1.5:1 at centre, <1.8:1 at edges

Impedance

50 Ohms - nominal

H Plane beamwidth

360° omnidirectional ± 0.5 dBd

E Plane beamwidth

65°

Maximum Power

100 Watts

Polarisation

Vertical

DC grounded

Yes

Construction

Grey PVC radome, 316 grade stainless steel radials and mount, mount section, grey PVC connector weather sealed housing and tri-metal plated N-female connector

Connector

Weather sealed N-type female

Dimensions

Height: 1.3m, Radial diameter/footprint: 500mm, Mount section: 300mm x 38.1mm O.D.

Weight - kg

6.5
