UHF sidemount dipole, 304 stainless steel, 400-520MHz, 250W, 0dBd – 290mm

Broadband UHF sidemount dipole, 304 stainless steel, 400-520 MHz, 250W, N-type female, 0 dBd - 290mm

Product code: B44SS

The B44SS stainless steel UHF sidemount dipole is designed and manufactured for UHF communications within the 400-520 MHz. The small design of the B44SS means its will take up minimal space on your mast/tower or structure. Stacking the B44SS into an array will increase gain and produce a directional pattern.

Specifications

Frequency

400-520 MHz - UHF, TETRA, LMR and GRN compatible

Bandwidth

Full frequency range stated - 120 MHz

Gain

0 dBd for a single bay, stacking increases gain

Tuning

Factory at 1.5:1 VSWR

Impedance

50 Ohms

Maximum Power

250 Watts

Polarisation

Vertical

PIM 3rd Order (2x20W)

better than -122dBc

DC grounded

Yes

Construction

Welded 304 stainless steel folded dipole, stand-off mount section, 500mm external RG58A/U and N-female connector

Connector

N-type female fitted to cable as standard or specify requirements

Dimensions

Dipole height: 290mm, Stand-off: 270mm x 31.8mm O.D.

Weight - kg

0.8

Wind load at 160kph

1.274kg, 0.012kN
