VHF and UHF broadband discone, 304 stainless steel, 70-1000MHz, N-type female, 100W, 0dBd – 1.2m

Broadband VHF and UHF discone antenna, 304 stainless steel, 70-1000 MHz, N-type female, 100W, 0 dBd - 1.2m

Product code: B51H-SS

The B51H-SS broadband discone provides a true omni-directional radiation pattern, low VSWR and genuine broadband coverage for both transmit and recieve across the full frequency band 70-1000MHz. Mount the B51H-SS using 2 x EB1-SS or 1 x UB3-SS.

download brochure
Download Installation Guide
Download Radiation Pattern

Specifications

Frequency

70-1000 MHz - VHF, Airband and UHF

Bandwidth

Full frequency range stated - 930 MHz

Gain

0 dBd - unity

Tuning

Factory at 2:1 VSWR

Impedance

50 Ohms

H Plane beamwidth

360° omnidirectional ± 0.5 dBd

E Plane beamwidth

83° at 100 MHz

Maximum Power

100 Watts

Polarisation

Vertical

DC grounded

No - surge protector such as LA-1793 required

Construction

304 grade stainless steel mount section and detachable radials, clear anodised cone head, machined black delrin insulator and tri-metal plated N-female connector

Connector

N-type female in base

Dimensions

Height: 1.2m, Radial diameter/footprint: 1.0m, Mount section: 300mm x 38.1mm O.D.

Weight - kg

9.5

Wind load at 160kph

15.501kg, 0.152kN
