Omni-directional all networks 4G & 3G spring base collinear, white, 825-960 & 1710-2190MHz, FME female, 30W, 6.2 and 3dBi – 900mm

Omnidirectional broadband 4G cellular mobile phone vehicle antenna, white, 825-960 & 1710-2190 MHz, 30W, FME female, 5m cable, 6.2 and 3 dBi - 900mm

Product code: SGDB-W

The benchmark for all cellular mobile phone vehicle antennas the SGDB-W super gain broadband 4G cellular antenna is a dual band capable upper and lower 4G mobile phone all-in-one vehicle antenna, suitable for mobile phone and wireless data applications on all networks lower and upper 4G networks. The SGDB-W broadband 4G cellular vehicle antenna comes standard with 5 metres of black RG58 cable with a FME female fitted for ease of installation through walls or vehicle firewalls. Mount the SGDB-W dualband 4G cellular vehicle antenna using the 12mm bolt in the spring base into a minimum 13mm hole or appropriate bracket with 13mm hole. For CEL-FI GO installations a SMA male termination is required or request a FME male to SMA adaptor when ordering.

download brochure
Download Installation Guide

Specifications

Frequency

825-960 MHz & 1710-2190 MHz - dualband 4G cellular mobile, all carriers

Bandwidth

Full frequency ranges stated

Gain

6.2 dBi at 825-960 MHz and 3 dBi at 1710-2190 MHz

Tuning

Factory at 1.6:1 VSWR

Impedance

50 Ohms - nominal

H Plane beamwidth

360° omnidirectional, ± 0.5 dBd

E Plane beamwidth

32°

Maximum Power

30 Watts

Polarisation

Vertical

DC grounded

Yes

Construction

White parallel fibreglass radome, aluminium ferrule, stainless steel barrel spring, 5m RG58 low loss cable and FME connector

Connector

FME female connector fitted to external 5.0m black RG58 low loss coaxial cable

Dimensions

Height: 900mm, Mount hole requirements: 13mm, External cable: 5m cable

Weight - kg

0.95

Wind load at 160kph

0.012kN, 1.237kg
