UHF 3 element square boom scaled Yagi, 380-520MHz, specify 20MHz, 6dBd – 700mm

UHF 3 element square boom scaled Yagi, 380-520 MHz, specify 20 MHz, 150W, N-type female, 250mm cable, 6 dBd - 700mm

Product code: Y403-SS

The Y403-SS directional scaled Yagi is designed for use within the UHF frequency range 380-520MHz, with a customer specified 20MHz, ideal for short distant directional UHF communications. Alternative models with higher gain and aluminium construction are available.

download brochure
Download Installation Guide
Download Radiation Pattern

Specifications

Frequency

380-520 MHz - UHF, TETRA, LMR and GRN compatible

Bandwidth

Specify 20 MHz bandwidth on order

Gain

6 dBd

Tuning

Factory at 1.5:1 VSWR

Impedance

50 Ohms - nominal

H Plane beamwidth

76° @ 3 dBd

E Plane beamwidth

57° @ 3 dBd

Maximum Power

150 Watts

Polarisation

Mount horizontal or vertical as required

Front-to-back

15 dB

DC grounded

Yes

Construction

Welded 304 grade stainless steel boom and elements, detachable folded dipole with 250mm external RG59 cable and tri-metal plated N-female

Connector

N-type female fitted to 250mm external RG59 cable as standard, or specify connector requirements

Dimensions

Length: 700mm, Widest element: 400mm, Boom: 25mm RHS

Weight - kg

039

Wind load at 160kph

0.047kN ; 4.751kg
