The Y406B-R round boom Yagi antenna is a medium gain, directional solution for UHF communications within the 400-420MHz range. The Y406B-R Yagi antenna is constructed with a 25mm Round boom design suitable for adjustable mount angle installation such as to a tapered tower leg utilising n A48-R mounting bracket. The Y406B working frequency includes worldwide emergency EPIRB 406-406.1MHz frequency as well as Government Radio network GRN 403-420MHz
400-420 MHz - UHF
Full frequency range stated - 20 MHz
9 dBd
Factory at 1.5:1 VSWR
50 Ohms - nominal
50° @ 3 dBd
46° @ 3 dBd
150 Watts
Mount horizontal or vertical as required - rotate to intended polarisation within bracket.
>15 dB
Yes
Welded aluminium boom, elements and folded dipole, 200mm external RG59 coaxial cable and N-female connector
N-type female fitted to 200mm external RG59 cable as standard or specify requirements - cost will be incurred
Length: 1.166m, Widest element: 400mm, Boom diameter: 25mm O.D.
0.6
6.1kg
